Spring Pogo Pin|Tsika & OEM

Dongguan Xinteng Electronics Co., Ltd. ndeimwe yevanonyanya kuvimbika vagadziri uye vatengesi vechirimo pogo pin|tsika & oem muChina, inoratidzwa nemhando zvigadzirwa uye sevhisi yakanaka. Welcome to wholesale bulk durable spring pogo pin|tsika & oem mu stock pano kubva kufekitari yedu. Zvakare, yakagadziridzwa sevhisi uye OEM & ODM sevhisi iripo.

Spring Pogo Pin -zvimedu zvitatu zvechitubu pogo pin ine chitubu chesimbi isina tsvina, dhiramu rendarira (chubhu), uye brass plunger. Iyo plunger inodzvanyirira chitubu chemukati kuti ibatane nemagetsi nepedhi yekubatanidza, socket, kana pamusoro, yobva yadzokera panzvimbo yayo yekuzorora kana mutoro wekusangana waburitswa.
The DIP tail pin pazvigaro zvekugadzika muPCB nemu-buri, zvichibvumira kuti chikamu chiite masaisai-chinotengeswa kana kuti ruoko-chitengeswa panzvimbo. Kana yangogadzikwa, chitubu chakaremerwa chinotarisana chakatarisana nekunze, chakagadzirira kusangana nechaja padhi, module interface, kana test point.

Dongguan Xinteng Electronics Co., Ltd. ndeimwe yevashanu vepamusoro vanogadzira pogo pini muChina. Iyo haingopi chete mazana mashanu akajairwa chitubu pogo pini kuti vatengi vasarudze kubva, asi zvakare inotsigira customization masevhisi (ODM/OEM).

Isu tinoitisa bvunzo dzezvakatipoteredza, zvemagetsi, uye zvemuchina pachirimo pogo pini uye tinogona kupa mishumo yebvunzo pakukumbira. Aya anotevera mamwe emishumo yebvunzo atinogona kupa, kusanganisira asi isina kugumira ku...

• Bata Impedance Test Report

Inoyera yekubata kuramba pane yakayerwa simba rekubatana pane imwe sampuli yehuwandu. Iyo Isingasviki kana yakaenzana ne50mΩ yakatarwa inoshanda kune yekutanga kuonana mamiriro; mushumo webvunzo unosanganisira kugovera data mukati memuenzaniso batch.

• Hupenyu Test Report

10,000 compression cycles inoiswa pasi pemamiriro akadzorwa, nekusangana kwekupokana kuyerwa panguva dzakatsanangurwa (kazhinji 1,000 macycle ekutanga e5,000 ekutanga, ipapo pakupera). Iyo yakatarwa yakatarwa inofanirwa kuchengetedzwa kuburikidza neiyo yakazara kutenderera kuverenga. Iyi ndiyo bvunzo yekutanga inosimbisa ukobvu hweplating uye kusarudzwa kwezvinhu zvechitubu zvechitubu chakaremerwa pogo pini.

• Salt Spray Test Report

48-awa kuratidzwa paASTM B117 (kana zvakaenzana). Inopfuura isina gomba, delamination, kana shanduko inoyerwa mukupikisa kubata panzvimbo yekusangana kwekunze. Kuyera uku kunobata nzvimbo zhinji dzemukati{{5}dzakati uye dzakareruka-maindasitiri ekushanda. Zvigadzirwa zvakagadzirirwa kuratidzwa kwenguva refu kunze kana nharaunda dzemugungwa zvinofanirwa kukurukura mamiriro ekushandisa nechikwata cheinjiniya isati yasarudzwa.

• Zvishandiso Zvinopfekeka & Smartwatches

Iyo 7.5mm kureba uye 1.50mm dhiramu dhayamita inokodzera mukati mezvirambidzo zvemba zve smartwatch yekuchaja ma cradles uye kusimba tracker docking contacts. Pa 3A, pini inobatika muchirimo ino inobata zvinodikanwa zvemazuva ano zvinopfekwa nekukasira-kuchaja maprotocol pasina nyaya dzemafuta pakubata kumeso.

• IoT Modules & Embedded Systems

Bhodhi-ku-kubhodhi makiyi ekubatanidza ekubatanidza mumagedhi eIoT anobvumira mamodule kutsiviwa mumunda pasina kuyerera majoini emasoja. Mutsara wematsutso akaremerwa pogo pini pane base PCB mateti ane mapedhi pane inochinjika module, ichiita iyo interface kuti iparadzanise uye yakavimbika pane yakaderera kutenderera kuverenga.

• Mu-Circuit Test (ICT) & Functional Test Fixtures

10,000-hupenyu hwekutenderera hwakakodzera-majegi ekuyedza vhoriyamu apo chigadziriso chinobata mazana mashoma emapuranga pazuva. Chitubu chakaremerwa pin yepini fomati - DIP-yakaiswa pafixture board, spring tip inobata unit iri muyedzo - inzira yakajairwa yekusvika kune divi rimwe chete kumapoinzi ebvunzo.

• Portable Medical Equipment

Iyo -40 madhigirii kusvika ku +105 madhigirii ekushandisa uye RoHS/REACH inotsigira kuteedzera kushandiswa mumidziyo inoona kuvharika kana kusiyanisa tembiricha yakakura. Iyo yakatsanangurwa yekubata simba (70g ± 20g) inowirirana zvakakwana zvekuti kutendeseka kwekubatanidza kunofanotaurwa pane ese ekugadzira kushivirira.

• Battery Management & Charging Interfaces

PaDC 12V / 3A, iyi pogo pini yechirimo inobata mapini ekutaurirana nedhata uye mitsetse yekuchaja ine mwero mumabhatiri pack magungano. Kune mapini emagetsi pamusoro pe3A, shanduro dzechinyakare dzine madhayamita makuru edhiramu ndiyo nzira yakakodzera (ona pazasi).


Mapoinzi mashoma anochengetedza nguva yeinjiniya isati yagadziriswa:

Kushanda sitiroko muganhu wakaoma, kwete nhungamiro. Manotsi ekudhirowa anoyambira pachena pamusoro pekudzvanya iyi pogo pini kupfuura 1.0mm inoshanda sitiroko. Iyo 1.4mm yakazara sitiroko ndeye mechanical hard stop - chitubu chinobata madziro ebhare uye hachikwanisi kufamba mberi. Kudzokororwa kubata pa hard stop kunoshandura zvachose chiyero chechirimo uye kubata simba, kushandura maitiro emagetsi ekubatanidza nenzira dzisingaonekwe kunze uye hazvizooneki kusvika kupikisa kwekubata kwadzikira.

Gadzira imba yako kana ndiro yekutungamira kuitira kuti nzvimbo yekubatanidza ingomanikidza plunger kusvika 0.7–1.0mm. Izvi zvinopa kuonana kwakanaka pasina kusvika kune yakaoma kumira.

Saizi yepedhi yenzvimbo yekubatanidza. Iyo 0.80mm plunger musoro dhayamita inoratidza padhi yekusangana ye 1.0-1.5mm dhayamita yekumhara yakavimbika. Mapedhi madiki anopotsa-kusangana pasi pepositional tolerance stacks; mapedhi mahombe akanaka nemagetsi.

PCB kuburikidza-nekurudziro yeburi. Kune iyo Φ0.50mm yepini yemuswe, pedzisa gomba dhayamita muhupamhi hwe 0.65-0.75mm inokodzera akawanda akajairwa FR4 maitiro. Siya inokwana annular ring ye solder zadza - 0.25mm shoma mhete yakafara iuriri hunonzwisisika.

Orientation kushivirira. Iyo dhizaini inotsanangura ± 2℃angular kushivirira kune maficha mu0℃-6℃renji. Pa automated press-fit or pick-uye-nekuisa nzvimbo, clearance for this tolerance in the guide housing inodzivirira kusunga panguva yegungano.

Ikozvino Rating:Madhayamita echigubhu ega ega uye misanganiswa yeplating inowedzera mabatirwo azvino kubva pa3A kusvika pa60A yemagetsi-ane nzara. Magadzirirwo epini epamusoro{{4}azvino aripo anoda chubhu geometry uye huremu hwaro hwezvinhu - taura nechikwata chemainjiniya nezvauri kuita, voltage, uye thermal.

Hurefu Hwose & Kushanda Stroke:Dzimba geometry dzimwe nguva inoda ipfupi kana kureba pini pane 7.5mm chiyero. Hurefu hwetsika hunogona kutsanangurwa; zivai kuti kuchinja hurefu hwese kunokanganisa sitiroko uye simba rekubata, izvo zvinofanirwa kudzokororwa-kubvumidzwa kune yega yega tsika.

Plating Type & Ukobvu:Goridhe, sirivha, kana nickel plating iripo. Sirivha inodzikisira kubata pakubata pekutanga asi inoda kungwarira kubata kudzivirira kusvibiswa munzvimbo dzine hunyoro. Nickel inodhura-inoshanda sarudzo apo kutenderera kuverengeka kwakadzikira uye nzvimbo yekushanda ichidzorwa zvakanaka-.

Mounting Style:DIP kuburikidza-gomba ndiyo yakajairwa neRG-1750-11P, asi SMT (surface mount), press-fit, uye threaded-barrel akasiyana espring contact pin anowanikwa mumagadzirirwo echivanhu.

Plunger Tip Geometry:Korona, yakanyungudutswa, yakanongedza, uye yakapfava tipi sarudzo inoenderana neyakasiyana mating epamusoro mamiriro. Korona kana muromo wakatsetseka unocheka nepakati pechiedza chepamusoro peoxidation pagoridhe{{1}mapadhi emahara; muromo wakatsetseka unokwirisa nzvimbo yekubata pane yakachena goridhe kana nickel nzvimbo.

Sample yekutungamira nguva yetsika chitubu chakaremerwa pogo pini zvigadziriso:7-15 mazuva ekushanda. Nguva yekufambisa yakawanda: 20 mazuva ekushanda. Minimum odha huwandu hwezvikamu zvakajairika: 1,000 zvidimbu.

Ndeupi mutsauko uripo pakati pekushanda sitiroko uye sitiroko yakazara pachirimo pogo pini?

Kushanda sitiroko (1.0mm paRG-1750-11P) ndiyo yakarongeka yerwendo rwekufamba panguva yenguva dzose - chinhambwe chinounzwa nepini yespring pogo inosvitsa zvakayerwa kuti ibatane uye kushanda kwemagetsi. Yakazara sitiroko (1.4mm) ndiyo mhedziso yemuchina muganho apo plunger mumuviri haigone kufamba mberi. Kushandisa sitiroko yekushanda senzvimbo yekushanda inopa muganho unodzivirira chitubu uye inoita kuti simba rekusangana rinogara mukati meiyo 70g ± 20g yakatarwa. Kugadzira kusvika kuzere sitiroko kuchaita kuti chitubu chidzike kunze nechero kutenderera kutenderera uye kupfupisa hupenyu hwesevhisi.

Iyo RG-1750-11P inogona kutakura kupfuura 3A here?

Iyo 3A chiyero ndiyo inoenderera DC yakakura kune yakajairwa gadziriso. Chiyero ichi chinoratidza musanganiswa wekubata kuramba (Zvishoma pane kana kuenzana ne50mΩ), nzvimbo yekubata, uye nzira yekupisa kuburikidza nedhiramu rendarira uye PCB pad. Yakachengetedzwa ikozvino pamusoro pe3A inoburitsa inodzivirira kupisa pane yekubata interface iyo inomhanyisa kupfeka kweplating uye inogona kukonzera kutadza kuonana nekufamba kwenguva. Tsika yechitubu pogo pini madhizaini ane hombe dhiramu madhayamita anowanikwa kune 5A, 10A, kana yakakwirira ikozvino zvinodiwa.

Ndeipi PCB gomba saizi yandinofanira kushandisa yepini yemuswe?

Pini yemuswe ndeye Φ0.50mm. Gomba rakapedzwa dhayamita ye0.65-0.75mm ndiyo yakajairwa kurudziro yehukuru hwemuswe uhwu pamabhodhi eFR4 ane HASL kana ENIG pamusoro pekupedzisira. Hukoshi chaihwo hunoenderana nemagadzirirwo emugadziri wako wePCB - simbisa chibooreso-ku-kupedza-paburi remuripo navo usati waburitsa faira rebhodhi.

Ko iyi spring pogo pin inopindirana ne nickel{{0}plated mating pads?

Ehe. Ndarama-ku-nickel contact yakajairika muPCB-level connectors. Bata resistance pane yegoridhe-yakapfekwa plunger kuenda ku nickel-plated pad interface inenge yakakwira zvishoma pane goridhe-ku-goridhe, uye nickel pamusoro pacho ichange ichiratidza mapfekero nekukasira. Kana application yako ichishandisa nickel pads uye ichida Zvishoma pane kana kuenzana ne50mΩ, kuyedza kuonana kuramba mushure memazana chiuru pasi pemamiriro ako ekusangana usati wakiya mudhizaini.

Ndeupi hudiki hweodha huwandu, uye masampuli aripo?

Yakajairwa yakaderera odha huwandu i1,000 zvidimbu zveRG-1750-11P chitubu pogo pini. Maengineering samples (5-10 zvidimbu) anowanikwa kuti aongororwe uye anowanzo kutumirwa mukati me2-7 mazuva ekushanda. Masamples ezvirongwa zvetsika zvinotakura mumazuva e7-15 ekushanda zvinoenderana nezvinodiwa zvekushandisa.

Iyi chitubu pogo pini inosangana neRoHS uye REACH zvinodiwa?

Ehe. Zvinhu uye machira epamusoro eRG-1750-11P - SUS304 simbi isina tsvina chitubu, ndarira C6801 mbiya uye plunger, goridhe plating - zvinoenderana nezvose zviri zviviri RoHS (Kurambidzwa Kwezvinhu Zvinokuvadza) uye REACH (Kunyoreswa, Kuongorora, Kudzora Kwemakemikari uye Kudzora. Mishumo yebvunzo iripo yekudhawunirodha kana pakukumbira.
